1500W Portable Power Station Supply With Pull And Handle Adjustable Portable Power Supply
Quick detail of Portable Power Station
Cycle life: >4000 cycles
Dimension: 483*170*241mm / Customized
Nominal Capacity: 24Ah
Charging Voltage: 14.6V, 3.7volt
Constant Discharge Current: 25A
Size: L168*W128*H103mm
Weight: 25kg
Battery Type: 24V LiFePO4 Battery
Optional: Bluetooth Monitoring APP
Capacity:12.8V 200Ah LiFePO4 Battery
OEM/ ODM: Accept OEM / ODM Customize
Certification: UN38.3/MSDS/KC
Description of Portable Power Station
1.higher charge/discharge cycles, about 3,000 cycles at 100% DOD (depth of discharge).
2. LiFePO4 cathode is intrinsically safer than the LiCo02 or the manganese cathode.
We provides a complete line of 12, 24 and 48 volt batteries for use in RV' s, boats, EV' s and off-grid applications and much more. Our wide variety of standard and high performance batteries ensure we have what you need, when you need it.
Specification of Portable Power Station
Specification | Parameter | LM12300 |
Nominal |
Voltage | 12.8V |
Capacity | 300Ah | |
Physical |
Dimension | 525*270*220 mm |
Weight | 37.6KG | |
Electrical |
Charge Voltage | 14.6V |
Discharge Voltage | 10V | |
Constant charge Current | 100A | |
Peak discharge current | 200A | |
Others |
Working Temperature | -20-65℃ |
Storage Temperature | 0-45℃ | |
Cycle Life | >4000 Cycles |
Module capacity | 5.73 kWh |
Total capacity | Up to 34 kWh |
Battery type | LiFePO4, lithium-ion |
BMS | Integrated, protects and charges each battery cell individually |
Charge-discharge cycles | 6000 (DoD 90%) |
Parallel operation | Up to 6 units |
Service life | 20 years |
Operating temperature | -10 to +50°C |
Size | 600x600x250 mm |
Weight | 65 kg |
Model | LFP100-12 | LFP200-12 | LFP300-12 |
Nominal Voltage(V) | 12.8 | 12.8 | 12.8 |
Nominal Capacity(Ah) | 100 | 200 | 300 |
Usable Capacity(Wh) | 1280 | 2560 | 3840 |
Dimension(mm) | 330*175*215 | 485*175*240 | 520*268*220 |
Weight(Kg) | 11 | 25 | 30 |
Cycle Life | ≥4000 @ 25℃ | ≥4000 @ 25℃ | ≥4000 @ 25℃ |
Working Temperature ℃ | -20~55 | -20~55 | -20~55 |
Discharge Voltage (V) | 12.8 | 12.8 | 12.8 |
Charge Voltage(V) | 13.5~14.6 | 13.5~14.6 | 13.5~14.6 |
Internal Impedance(mΩ) | ≤20 | ≤10 | ≤10 |
Charge / Discharge Current (A) | charge:50 | charge:40 | charge:60 |
discharge:50 | discharge:40 | discharge:60 | |
Design Life(Years) | 20 | 20 | 20 |
Feature Of Portable Power Station
Function of Portable Power Station
Bluetooth Function
LiFePO4 technology offers high-powered cell performance compatible with lots of lithium-ion application to deliver more power and extend long life. Also built with bluetooth function allow you to read battery status freely anytime.
Self-heated Function
To relieve winter range anxiety in some freezing environment, the BMS can bring with self heating function. Resistance heating rapidly warms the inside of battery. Start heating temperature:≤0°C. Stop heating temperature:≥10°C. Can improve battery charge / discharge performance.
Application of Portable Power Station
⇒ UPS, Solar, Wind, Mobile generator, Back up power
⇒ Solar power bank, Solar LED lighting, Solar street light
⇒ Scooter, E-bike, Golf cart, E-motor, E-tour car, tricycle
⇒ Electric drill, electric saw, lawn mower and so on
⇒ Remote control cars, boat, aircraft, toys
⇒ Medical devices, equipment and portable equipment
⇒ Bluetooth, GPS, Wearable device, Power supply, Wireless
1. Back-up System and UPS: Telecom Base / CATV system / Computer Server Center / Medical Instruments / Military Equipment.
2. Energy Storage: Solar-Wind Power System / City Grid (On/Off) / Community and Family / RV Motorhome / Golf Carts Battery / Boat Marine Yachts / Electric Skateboard / Vehicle.
3. Other Applications: Security and Electronics / Mobile POS, Mining Light/ Torch / LED Light / Emergency Light / LED Backup / Engine Starting Battery,etc.
The lifepo4 battery pack is widely used for RV, Camper, Yacht, Golf cart, Solar energy storage system, electric bicycle, electric bike, electric wheelchair, power tools, electric scooter,emergency light,etc
CAPACITY
150 ampere hours. Lithium batteries provide consistent power for all 150 amp hours. MaxLi LiFePO4 batteries have a flat voltage curve, which means they have a steady power output as the battery discharges.
LIFECYCLES (BATTERY LIFESPAN)
Up to 100% capacity for 3,000 cycles in recommended conditions. The typical SLA has 400 cycles. Lithium batteries last so long that the price per use is a fraction of traditional batteries.
Smart Built-in BMS
passive balancing (active balance optional), low voltage cutoff, high voltage cutoff, short circuit protection and temperature protection for increased performance and longer life. Besides, Bluetooth function for option that enables to monitor battery status, such as, voltage, capacity and so on.
Period of Warranty
The period of warranty is 36 months from the date of shipment. MAXLI guarantees to give a replacement in case of battery with defects proven due to manufacturing process instead of the customer abuse and misuse.
Portable Power Station Performance and Test Conditions
1. Standard test conditions
Test should be conducted with new batteries within one week after shipment from our factory and the batteries shall not be cycled more than five times before the test. Unless otherwise specified, test and measurement shall be done under temperature of 20±5℃ and relative humidity of 45~85%. If it is judged that the test results are not affected by such conditions, the tests may be conducted at temperature 15~30℃ and humidity 25~85%RH.
2. Standard Charge/Discharge
Standard Charge: 0.2C
Charging shall consist of charging at a 0.2C constant current rate until the battery reaches 14.6V. The battery shall then be charged at constant voltage of 14.6 volts while tapering the charge current. Charging shall be terminated when the charging current has tapered to 0.05CA. Charge time: Approx 7.0h, The battery shall demonstrate no permanent degradation when charged between 0 ºC and 45 ºC.
Standard Discharge: 0.2C
Battery shall be discharged at a constant current of 0.2C to 10V @ 20º ± 5C
Warning & Tips
1. Keep the battery against high temperature. Otherwise it will cause battery heat, get into fire or lose some functions and reduce the life;
2. When the battery run out of power, please charge it within 15 days;
3. Please use the original or recommended charger for this battery;
4. If the battery leaks and get into the eyes or skin, do not wipe, instead, rinse it with clean water and see doctor immediately;
5. Do not use the battery when there exist abnormal conditions such as odour, discoloration, noise, leakage, serious deformation, etc.
6. Please far away from children or pets.
Why Choose US:
1. We offer one-stop power solutions, which saves design time and cost for customer:
-- Pack design / External Case design / BMS design
2. Strict quality control system which enhances customers' competitiveness:
-- 100% PCM test by IQC
-- 100% Capacity test by OQC
3. Delivery on time & excellent service:
-- Fast Delivery in 10 days if stock
-- 8h response & 48h solution
4. Experienced R&D team, be customer's professional power solution consultant:
-- Comprehensive Battery Test Center (Safety and Reliable test)
-- Powerful ODM Ability to Afford Customized Design Requirement
FAQ:
Q1. What is the biggest difference between your battery and other suppliers:
A: Safest with longer lifespan.
Q2. How about your Portable Power Station delivery time?
A: 1-25 workdays after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q3: How about your warranty?
A: 3years warranty
Q4. Is this Portable Power Station safe?
A: Passed the overcharge, over discharge, over temperature, short circuit, acupuncture and other safety tests, no fire, no explosion at any circumstance; price to ensure our customers benefit ;
